JEGA FLEX SERIES

THE JEGAFLEX SERIES HAS BEEN USED AS A 100% REPLACEMENT OF PVA SINCE 1998.

IT HAS NOT BEEN COMMERCIALIZED WIDELY AS THE PRICE OF PVA UNTIL RECENTLY MADE IT LESS ATTRACTIVE THAN PENFLEX, EVEN THOUGH JEGAFLEX HAS CERTAIN PROPERTIES THAT MIGHT BE MORE SUITABLE FOR THE NEWER AND HIGHER SPEED LOOMS IN THE MARKET TODAY. THE JEGAFLEX SERIES HAS IDENTICAL CHEMISTRY TO THE PENFLEX SERIES. WE WOULD LIKE TO STRESS THIS STRONGLY AS THE PATENT PROTECTION IN EFECT IS BASED ON THIS CHEMISTRY.

JEGAFLEX DECREASES THE DEPENDENCY OF TEXTILE MILLS IN THE USE OF POLYVINYL ALCOHOL (PVA) BY REPLACING PVA ON A KILO [100%] IN SIZING FORMULATIONS FOR SPUN YARNS.

UNFINISHED FABRICS CONTAINING PVA BASED SIZING FORMULAS ARE NOT ACCEPTED BY MANY FINISHING MILLS DUE TO ENVIRONMENTAL REGULATIONS. [DESIZING THESE FABRICS CAN LEAD TO SEVERE FINANCIAL PENALTIES.] JUST AS THE ‘PENFLEX SERIES, THE JEGAFLEX SERIES OF PRODUCTS HAS SOLVED THIS PROBLEM. BY REPLACING PVA WITH JEGAFLEX, YOU WILL ACHIEVE HIGHER WEAVING EFFICIENCIES, A HIGHER PERCENTAGE OF GRADE A FABRICS AT A LOWER COST, AND REDUCTION IN DESIZING COSTS.

TYPICAL PROPERTIES: [HV]

PHYSICAL FORM	OFF WHITE POWDER, FREE FLOWING FORM FEELS GRITTY TO THE TOUCH
ODOR	SLIGHT ORGANIC – SIMILAR TO PENFLEX
PH [10% SOLUTION]	5.0 TO 8.0
MOISTURE	12% MAXIMUM- NORMAL 8-10%
BROOKFIELD VISCOSITY	30 – 60 CPS @ 8.5 % SOLIDS 87 DEGREES C VISCOSITIES WILL VARY ACCORDING TO THE TYPE OF VISCOSITY DESIGNED ACCORDING TO MILL WEAVING  NEEDS
ZAHN CUP VISCOSITY	16 – 20 SEC #3 @ 8.5 % SOLIDS 87 DEGREES C

DESCRIPTION

JEGA FLEX SERIES OF PRODUCTS CAN BE DELIVERED IN DIFFERENT VISCOSITIES. THEY CAN BE MANUFACTURED TO MATCH THE VISCOSITY OF THE PVA TO BE REPLACED. THEY ARE COMPATIBLE WITH ALL STARCHES, WAXES, LUBRICANTS, ANTISTATIC AGENTS, HUMECTANTS, SURFACTANTS AND OTHER PRODUCTS NORMALLY USED IN SIZING FORMULAS.

JEGA FLEX ALSO CAN REPLACE ALL BINDERS COMMONLY USED IN SIZING FORMULAS SUCH AS CMC, ACRYLICS [BOTH LIQUIDS / POWDER], AND POLYESTER RESINS. JEGA FLEX SERIES CAN BE USED IN NATURAL, SYNTHETIC, OR BLENDED SPUN FIBERS, INCLUDING COTTON, WOOL, SILK, RAYON’S, POLYESTERS, NYLONS, VISCOSE, AND ACETATE.

ADVANTAGES/BENEFITS

THE JEGAFLEX SERIES OF PRODUCTS DIFFERENCES AS COMPARED TO THE PENFLEX SERIES ARE AS FOLLOWS:

1) THE PENFLEX SERIES PROVIDED A DRY FILM COMPARED WITH PVA. PVA IS ONE OF THE GREAT HYGROSCOPIC AGENTS IN A SIZING FORMULA, ALLOWING THE YARN TO REABSORB HUMIDITY IN THE WEAVE ROOM AS REQUIRED. WHEN ONE REPLACED THE PVA WITH THE PENFLEX ON A 100% BASIS, THE TENDENCY WAS TO GET A FILM THAT WAS DRY IF THE OTHER INGREDIENTS IN THE FORMULA WERE NOT HYGROSCOPIC ENOUGH. THIS DRYNESS LED TO SOME FLAKING THAT WAS AT TIMES NOT AN ACCEPTABLE AND WAS MISCONSTRUED AS DUE TO LACK OF ADHESION.

WITH JEGAFLEX, THE SIZE FILM RETAINS ITS HYGROSCOPICITY OR ABILITY TO REABSORB HUMIDITY EVEN WHEN REPLACING THE PVA 100%. YOU WILL NOTICE ABSOLUTELY NO FLAKING EITHER IN THE FRONT END OF THE SIZING MACHINE OT THE LOOMS DURING THE WEAVING PROCESS. THIS ABILITY TO RETAIN MORE MOISTURE IN THE FILM WILL ALSO RESULT IN A VERY FLEXIBLE FILM NECESSARY IN SPEEDS OVER 1000 RPM’S.

2) WEFT STOPS REDUCED DUE TO AN IMPROVED FIBER LAYDOWN- SEE PICTURES- [the chemistry that provides the ability for better fiber lay down is described in PATENTS 4, 301, 017- 4, 375, 535, - 5, 130, 394]

3) ABILITY TO REPLACE NOT ONLY PVA, BUT OTHER BINDERS IN THE FORMULA TO INSURE LOWER COSTS.

4) EXCELLENT VISCOSITY STABILITY OVER A WIDE TEMPERATURE RANGE.

5) IN ADDITION TO THE REPLACEMENT OF THE PVA, YOU WILL ALSO BE ABLE TO REDUCE OTHER BINDERS IN THE FORMULATION. THIS WILL REDUCE COSTS SUBSTANTIALLY.

6) WITH THE JEGAFLEX SERIES, THE SIZE ADD ONS CAN BE UP TO 20% LESS, STILL PROVIDING ADDITIONAL COSTS SAVINGS.

TECHNOLOGY: WHY CAN YOU WORK WITH LOWER SPU% IN MOST CASES????

JEGA FLEX PROVIDES GREAT IMPROVEMENT IN THE COATING OF THE YARN. ENCAPSULATION IS THE AMOUNT OF SIZE ON THE SURFACE OR THE OUTSIDE OF THE YARN. CONVENTIONAL SIZING PRODUCTS ONLY ENCAPSULATE APPROXIMATELY ONLY 270 DEGREES OF THE YARN SURFACE.

JEGA FLEX ENCAPSULATES APPROXIMATELY 360 DEGREES OF THE YARN SURFACE. THE EFFECT OF THIS COMPLETE ENCAPSULATION MEANS REDUCED SIZE AND FIBER SHEDDING DURING THE OPENING OF THE WARP SHEET AT THE FRONT OF THE SIZING MACHINE. THIS CREATES LOWER HAIRINESS AND RESULTS IN HIGHER WEAVING EFFICIENCIES.

JEGA FLEX, WHEN ADDED AS A PVA REPLACEMENT IN A STANDARD SIZE FORMULA, IMPROVES THE OVERALL PENETRATION OF THE SIZE IN THE YARN BUNDLE. THIS CONTRIBUTES TO A STRONGER YARN WITH REDUCED SHEDDING DURING SIZING AND WEAVING. REDUCED SHEDDING MEANS LESS YARN BREAKS AND BETTER FABRIC QUALITY.

IMPROVEMENTS IN BOTH ENCAPSULATION AND PENETRATION CAN BE CONFIRMED MICROSCOPICALLY.

DUE TO BETTER ENCAPSULATION AND PENETRATION, YARNS SIZED WITH JEGA FLEX IMPROVE FIBER LAY OR HAIRINESS WHICH PROVIDES LESS TENDENCY TO ADHERE OR CLING TO EACH OTHER DURING WEAVING , MAKING FOR A CLEAR OPENING BETWEEN THE WARP SHEETS THAT LEADS TO HIGHER EFFICIENCIES IN WEAVING AND BETTER FABRIC QUALITY.

50/50 T/C 35/1 MJS Sized with Standard Mill Formula	50/50 T/C 35/1 MJS Sized with JEGA FLEX Formula

APPLICATION

JEGA FLEX SERIES ARE UNIQUE SIZING MATERIALS THAT CAN BE USED AS DIRECT REPLACEMENTS FOR PVA AND OTHER BINDERS IN THE SIZE FORMULA.

BASED ON CUSTOMER REQUESTS, WE CAN INCORPORATE OTHER SIZING ADDITIVES IN THE JEGA FLEX PRODUCT EITHER ON A PERCENTAGE DECIDED BY THE CLIENT OR BASED ON OUR APPLICATIONS TECHNOLOGY. WE CAN INCORPORATE WAXES, LUBRICANTS, SOFTENERS, DEFOAMERS, ANTISTATIC AGENTS AND OTHER COMMONLY USED ADDITIVES TO THE PENFLEX PLUS PRODUCT.

DESIZING

JEGA FLEX PROVIDES EXCELLENT DESIZE PROPERTIES. OUR JEGA FLEX TECHNOLOGY IS EASILY REMOVED USING ONLY WATER AT TEMPERATURES ABOVE 90 DEGREES C. THE FINAL DESIZE RECIPE WOULD DEPEND, HOWEVER, OF THE DESIZABILITY OF THE OTHER CHEMICALS USED BY THE MILL IN THE SIZE FORMULA.

VISCOSITY INFORMATION

Viscosity vs Solids Testing
Product	% solids tested
	6	8	10	12	14
Penflex CS9010-LV	44	60	69	119	165
Penflex CS9010-M	54	77	97	164	345
Penflex CS9010-HV	59	79	217	436	744
Jegaflex HV	56	80	138	230	368
Viscosity Stability Study
Product	Time (mins)
	10	20	30	40	50	60
Penflex CS9010-LV	480	95	78	70	66	62
Penflex CS9010-M	768	144	132	120	112	100
Penflex CS9010-HV	900	315	290	280	260	238
Jegaflex HV	770	204	180	152	140	126
All tests were run at 90C/194F
Brookfield run with #2 Spindle @ 50 rpm

ENVIRONMENTAL ASPECTS

JEGA FLEX SERIES COMPLY WITH THE TOXIC SUBSTANCES CONTROL ACT (TSCA) AND ARE MANUFACTURED UNDER 1SO-9001 - 2000 CERTIFICATION IN AN ENVIRONMENTALLY SAFE FACILITY THAT SERVES AS A MODEL FOR OTHER OPERATIONS IN THE CHEMICAL INDUSTRY.

PACKAGING AND STORAGE

JEGA FLEX PRODUCTS ARE PACKED IN 25 KILO, PAPER BAGS SUITABLE FOR EXPORT. IT IS PREFERABLE TO STORE IN A DRY AREA.

PATENT INFORMATION

AS PER THE PENFLEX SERIES, OUR PATENTED INVENTION IS PROTECTED BY NUMEROUS WORLDWIDE PATENTS INCLUDING USA # 5,707,720 DATED JANUARY 13, 1998. IT PROVIDES A METHOD OF PREPARING A UNIQUE SIZING PRODUCT COMPRISING OF A REACTION PRODUCT OF STYRENE - BUTADIENE COPOLYMER GRAFTED INTO STARCH. THE STYRENE - BUTADIENE COPOLYMER IS MADE SOLUBLE THROUGH THIS REACTION. THE RESULT IS THE PENFLEX - JEGAFLEX SERIES OF PRODUCTS. WE USE THE WORD SERIES AS THE PRODUCTS COME IN DIFFERENT VISCOSITIES TO MATCH THE VARIOUS PVA’S IT IS REPLACING.

FORMULATION EXAMPLE

Style 40/1 x 40/1 144 x 111 63” 3/1
Loom Toyota ZAT 710 1054 rpm’s

Standard Formula		Test Formula
Water	800 liters	Water	800 liters
50 Fluidity Starch	100 kilos	50 Fluidity Starch	100 kilos
Kuraray 613	30	Kuraray 613	0
Size CT	48 [liquid]	JEGAFLEX	30
Polytex [40%] softener	14	Size CT	38 [liquid]
Standard SPU%	15%	JEGAWAX	6
STANDARD EFF %	94	SPU%	13%
WARP STOPS SHIFT	10-11	TEST EFFICIENCY %	94.6
		WARP STOPS SHIFT	8
